Construction: Recessed ceiling back box features universal adjustable mounting brackets with quick-fit retaining clips to suit most ceiling types • Full size universal, self-adhesive Chevron arrows with template enable on-site configuration • Lens Panel is “Last-to-Assemble” snap-in for versatility and ease of installation • Hinged retaining springs eliminate exposed mounting hardware on recessed model • Slim line low profile surface mount housing eliminates need for recessing box in wall mount applications • Low profile recessed housing is suitable for old or new work installations and is type IC Rated • Modular design provides ease of installation and matching configurations • Quality brushed aluminum sealed finish is standard, optional White, Black, brushed painted Brass finishes available. Consult factory for custom finishes. • Contoured, crystal clear laser formed edge lit lens • Custom legends with white LED light source available to order • Precision pressure die cast aluminum legend holder, trim and surface mount housing • Available with a range of information signage or custom graphics to order • Recessed AC Indicator and Test Switch
• Unique electronic driver circuit provides current control and protection ensuring optimum LED efficiency and life • Available with Master/Remote combinations • Zero current LVCO ensures positive charge acceptance following extended discharge • Brownout sensing assures emergency illumination during periods of low line voltage • All versions feature fully integrated electronic components • Universal 120/277 VAC field selectable input • Battery Diagnostic Circuit monitors battery status, detects cell failure and issues alert of reduced capacity and the need to replace battery • Diagnostic Battery Monitoring on all “EM” models • Premium long life high temperature rated, fused Nickel Cadmium battery, operating temperature 10º to 40ºC
