PARKER

PARKER

Global Core Hydraulic Hose

Condition: New

Size: 385' 3000 PSI 21 MPa

Color: Black

MPN/Model: 387TC-6-RL

Description:

• ½ ISO 18752 minimum bend radius. Low force to flex for ease of installation.

• 3,000 psi constant working pressure in all sizes.

• Exceeds ISO 18752 performance specification (AC, BC & CC).

• Synthetic rubber inner tube provides a wider range of fluid compatibility.

• TC cover provides 80 times the abrasion resistance compared to Standard rubber cover hose.

• ST cover provides 450 times the abrasion resistance compared to Standard rubber cover hose.

• Reinforcement: One- or two-braid steel wire for sizes -4 to -16

• Minimum Bend Radius inch: 2-1/2

• Hose O.D. inch: 0.69

• Working Pressure MPa: 21

• Minimum Number of Cycles: 200,000

• Hose I.D. inch: 3/8

• Temperature: 100°C (212°F)

• Impulse Pressure(% of MWP): 133%

• Hose I.D. mm: 10

• Package Type: RL - Reel

• Weight kg/m: 0,34

• Hose O.D. mm: 17,4

• Compatible Fittings: Parkrimp 43 Series

• Inner Tube: Synthetic rubber

• Grade: A

• Application: Petroleum base hydraulic fluids and lubricating oils

• Working Pressure psi: 3000

• Minimum Bend Radius mm: 65

• Temp. Range: -40˚F to +257˚F (-40˚C to +125˚C)

• Weight lbs/ft: 0.23

• Fittings: 43 Series, sizes -4 to -20

• Cover: Synthetic rubber abrasion resistant

• Series: 387

• Inner Diameter: 3/8

• Working Pressure (psi): 3000

Condition: New

Size: 385' 3000 PSI 21 MPa

Color: Black

MPN: 387TC-6-RL

PayWut SKU: CW07362
