| Body Material: |
Brass |
| Maximum Operating Pressure: |
300 psi |
| Media: |
Low pressure fluids and compressed air |
| Coupling Half: |
Coupler |
| Minimum Operating Temperature: |
-40 °F |
| Maximum Operating Temperature: |
250 °F |
| Seal Material: |
Nitrile |
| Valve Type: |
Tubular |
| Application: |
Air |
| Plating Type: |
na |
| Specifications Met: |
Connects with A-A-59439 (MIL-C-4109F, ISO 6150-B |
| Sleeve Type: |
Manual |
| Lock Type: |
Locking balls |
| Connection Hose I.D. (inch): |
na |
| Connection Thread Size (inch): |
1/4 - 18 |
| Thread Style: |
Female |
| Connection Type: |
NPTF |
| Body Size (inch): |
1/4 |
